Description
The Rais Q-Tee II now has a new curve appeal! The Q-Tee II C has rounded sides and curved glass door that rethinks the design of this beautifully contoured stove series.
Equipped with “cabinet-style” door makes opening and closing the firebox a breeze.
Functional and stands out with it’s superior environmental performance of .9/gph emissions.
Rais Q-Tee II C is regarded as one of the cleanest burning non-catalytic stoves on the North American market. The large fire box of this stove accepts a 17″ piece of wood and can burn for many hours into the night. The large window with stay-clean technology offers a magnificent view of the flames. The door is available in a steel frame, or can be enhanced with an extra piece of glass on the outer surface as an option, so the whole door appears to be glass. Base comes standard with full cover plate, or can also be taken out to be used as a full open wood storage area. Outside-air adapter system is also an option.
Click here for CBI test report for Qtee-II C
Click for Manual
::SPECIFICATIONS::
HEAT
BTu output — 27 kBTu
Heat range (min-max) — 10-27 kBTU
Heating capacity (25-68 degrees F) — 1400 sq ft
Emissions — 0.9 g/hr
Efficiency — 75+%
DIMENSIONS (W-D-H)
Stove Exterior — 26 x 19 x 42 1/3″
Firebox Interior — 17 1/2 x 9 3/5 x 10 1/5″
Log Length — 17″
Pipe Diameter — 6″
Distance from center of top exit to the back edge of the top plate — 5 1/8 ”
Distance from floor to center of top exit — 38 2/5″
Distance from floor to center of rear exit — 33 2/5″
Floor to center of outside air connector — 4 3/10″
DISTANCE TO FLAMMABLE MATERIAL
Distance to combustible side wall — 14″
Distance to combustible back wall — 12″
Corner Clearance to Combustible — 11″
WEIGHT
Stove — 439 LB
| FEATURES | STANDARD | OPTION |
| Color: Black | – | – |
| Glass Door | – | X |
| Heat Shield | X | – |
| Outside AirSystem | – | X |
| Shaker Grate & Ash Pan | X | – |
| Steel Door with Glass | X | – |
| Top or Rear Smoke Exit | – | X |
| Air-Cooled Handle | – | – |
